The GB-ER series combines original Magnescale technology and legendary durability with a built-in reference point.

  • Excellent durability against workshop conditions - resistant to oil, dirt, shock and vibration.
  • Compact design for space saving instalation
  • Resolution: 0,5 μm
  • Precision: (5+5L/1000) μm
Specifications
Model GB-ER
Effective Length (ML) L: mm 50, 100, 150, 200, 250, 300, 350, 400, 450, 500, 550, 600, 650, 750, 850, 950, 1050, 1250, 1400, 1600, 1850, 2050, 2200
Overall Length 150 - 200 mm: ML + 104 mm | 250 - 2200 mm: ML + 120 mm
Max. travel L + 14 mm (50-200mm) Lungime totală (250-2200 mm) | L + 30 mm (250-2200 mm) Lungime totală (50-200 mm)
With or Without Centerfootplate With ML: 1050 - 2200 mm, Without ML: 50 - 950 mm
Precision at 20ºC (5 + 5L / 1000) μm
Rezoluție 0,5 μm
Response speed 60 m/min
Reference point Standard: Center of the Scale, User Defined Point also Available
Mounting Parallelism ± 0,1 mm
Expansion Coefficient (11±1) x 10-6/ºC
Operating Temperature 0ºC ~ 40ºC
Storage Temperature -20ºC ~ +50ºC
Head Cable Length 0,3 m
Cable Length 3 m
Protective Design Grade Scale: IP65 (Unitate interpolare: IP30)
Input/Output Signal Output Signal  A/B quadrature signal, Z signal
Power Supply +5 VDC ±5%
Connector D-sub 9 pins
Power Consumption max. 200 mA
