Standard-Check Penetrant System

Standard-Check Penetrant System

Specifications

CONTRAST (RED-WHITE) PENETRANT TESTING



         The Standard-Chek penetrant system is a system widely used for parts testing in engineering and automobile industry, ship and boiler building, welding, etc. in a temperature range from –5°C to +50°C. For testing at higher temperature (from 65° С to 180° С) the SUPER-CHEK penetrant system has been developed specially.

            The Standard-Chek penetrant system was tested and approved in accordance with EN ISO 3452-2, KTA and meets the requirements of Lloyd's Register of Shipping, Bureau Veritas, Bureau Central Hollandais, Germanischer Lloyd, MIL-I- 25135/QPL-25135, AMS 2644, ASME Boiler and Pressure Vessel, ASTM E-165, ASTM-E1417.
           The low content of sulfur and halogens was ascertained and confirmed according to ASTM E 165-02 and ASTM D 516-02, as well as to requirements of KWU and EN ISO 3452-2.

Product Sensibility Level Removal Method Product Information
Standard-Chek Cleaner No.1 NA NA Alcohol-based cleaner, fast evaporating
without residues.
  Delivery Form:
Spray 500 ml
Can 1 L
Can 10 L
Cask 200 L
Standard-Chek No.2
Penetrant
Class II
(high sensibility) acc. to DIN EN ISO 3452-2
«A» - water washable
«C» - solvent removable
«E» - water and solvent removable
Red penetrant (Type II) with a wide
application range used for inspections in
welding, petrochemical, pharmaceutical
industries and general metal working.
  Delivery form:
Spray 500 ml
Can 1 L
Can 10 L
Cask 200 L
Standard-Chek Rot2003 Penetrant Class II
(high sensibility) acc. to DIN EN ISO 3452-2
«A» - water washable
«C» - solvent removable
«E» - water and solvent removable
Red fluorescent penetrant (Type III)
without azo dye. Almost odor-free. Very
well washable. Fluorescent under UV
irradiation for brilliant indications.
  Delivery Form:
Spray 500 ml
Can 1 L
Can 10 L
Cask 200 L
Standard-Chek No.3 Developer NA NA
Alcohol-based, fine-grained white
powder suspension being applied as a
homogenous thin layer. Short drying
time.
  Delivery Form:
Spray 500 ml
Can 1 L
Can 10 L
Cask 200 L
